2410-K2 HMF 2410-K2 Specifications & Technical Data (2016—2021)

The HMF 2410-K2 is a truck-mounted loading crane manufactured by HMF from 2016 to 2021. It has a weight of 2.285 tons and a carryi…

The HMF 2410-K2 is a truck-mounted loading crane manufactured by HMF from 2016 to 2021. It has a weight of 2.285 tons and a carrying capacity of 2.76 tons. The crane requires 33 kW of power and has a load torque of 224 kNm. Its maximum carrying capacity is 5.27 tons and it can reach up to 8.2 meters. The crane's standard boom extends up to 8.3 meters. The machine itself has a length of 2.5 meters, a width of 0.885 meters, and a height of 2.295 meters. At a reach of 4.3 meters, the crane can perform its loading operations.

Hydraulic loading cranes HMF 2410-K2

Technical specs - 2410-K2 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
224 kNm
machine length
2.5 m
machine width
0.885 m
machine height
2.295 m
max. standard boom
8.3 m
Carrying capacity
2.76 t
at max. reach
8.2 m
Weight
2.285 t
max. carrying capacity
5.27 t
at reach
4.3 m
Required power
38 kW
Model series
K

More technical details, like: load of additional jib, max. hook height are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
No
Articulated boom overstraining
No

Download datasheets (PDF)

HMF 2410-K2 overview

Lifting

Single Link Arm System

The HMF single Power Plus link arm system has an excellent lifting capacity at long reach and works particularly fast when loading and unloading with grab.


HMF Radio Remote Control type RC

HMF radio remote control provides the operator with all advantages and possibilities for remote control of the crane functions and important safety functions. The crane operator can move in the entire working area and can at any time position himself optimally and safely in relation to the lifting task. The crane is equipped with the HDL system which automatically adapts the crane speed to the working situation when it is exposed to a lot of stress.


Jib

Extra Valves with Variation

A well-known and usual hose routing to the end of the extensions means that 1 or 2 extra valves are fed in sturdy hose guides alongside the jib extension system. If further efficient protection of the hoses is required, 1 or 2 extra valves can be fed in internal hose reels and lie particularly well protected.
