1720-K4 HMF 1720-K4 Specifications & Technical Data (2016—2021)

The HMF 1720-K4 is a truck-mounted loading crane manufactured by HMF from 2016 to 2021. It has a weight of 2.035 tons and a carryi…

The HMF 1720-K4 is a truck-mounted loading crane manufactured by HMF from 2016 to 2021. It has a weight of 2.035 tons and a carrying capacity of 1 ton. The required power for this machine is 28 kW, and it has a load torque of 144 kNm. The maximum carrying capacity of the crane is 3.29 tons, and it can reach a maximum distance of 12.7 meters. The machine's standard boom length is also 12.7 meters. It has a machine length of 2.5 meters, a width of 0.825 meters, and a height of 2.245 meters. The crane is equipped with a remote control for convenient operation.

Hydraulic loading cranes HMF 1720-K4

Technical specs - 1720-K4 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
144 kNm
machine length
2.5 m
machine width
0.825 m
machine height
2.245 m
max. standard boom
12.7 m
Carrying capacity
1 t
at max. reach
12.7 m
Weight
2.035 t
max. carrying capacity
3.29 t
at reach
4.5 m
Required power
38 kW
Model series
K

More technical details, like: load of additional jib, max. hook height are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
Yes
Adjustable pivoting
No
Articulated boom overstraining
No
