1720-K4 HMF 1720-K4 Specifications & Technical Data (2008—2021)

The HMF 1720-K4 is a truck-mounted loading crane manufactured by HMF from 2008 to 2021. It has a weight of 1.9 tons and a carrying…

The HMF 1720-K4 is a truck-mounted loading crane manufactured by HMF from 2008 to 2021. It has a weight of 1.9 tons and a carrying capacity of 1 ton. The crane requires a power of 28 kW and has a load torque of 144 kNm. It can reach a maximum carrying capacity of 3.29 tons and has a maximum reach of 12.7 meters. The machine's standard boom length is also 12.7 meters. The machine itself has a length of 2.5 meters, a width of 0.825 meters, and a height of 2.25 meters. At a reach of 4.5 meters, the crane is equipped with adjustable pivoting, electronic load torque limitation, and hydraulic brace support.

Hydraulic loading cranes HMF 1720-K4

Technical specs - 1720-K4 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
144 kNm
machine length
2.5 m
machine width
0.825 m
machine height
2.25 m
max. standard boom
12.7 m
Carrying capacity
1 t
at max. reach
12.7 m
Weight
1.9 t
max. carrying capacity
3.29 t
at reach
4.5 m
Required power
28 kW
Model series
K

More technical details, like: load of additional jib, max. hook height are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
Yes
Electronic load torque limitation
Yes
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
Yes
Articulated boom overstraining
No

Download datasheets (PDF)
