    HMF 1420-K5 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    The 1420-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1420-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The HMF 1420-K5 can be grouped in the smallest machine segment in the hydraulic loading crane category. Dimensions of 1420-K5 model are 2.5m length and 0.825m width. The longest standard boom the HMF 1420-K5 can have is 14.9m. The carrying capacity of this Hydraulic Loading Crane is 2.59t. HMF 1420-K5 has 116kNm in load torque.

    Articulated boom overstraining, Hydr. Brace support and High seat are not provided on this model as of 2018. Get the original HMF 1420-K5 datasheet for even more detailed specifications and machine details. You can download it for free in German, Spanish, French and English on LECTURA Specs.

    Manufacturing of this model is still ongoing.

    HMF currently produces 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm - the most visited on LECTURA Specs are 6020-K6 , 340-K2 , 260-T2. Ranked in the LECTURA index at #3564, this 1420-K5 hydraulic loading crane has models that date from 2016 to 2018. Want more detailed specifications? Download the latest HMF 1420-K5 specs data sheet on LECTURA Specs today!

    Technical specs - 1420-K5 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 116 kNm
    • machine length 2.5 m
    • machine width 0.825 m
    • machine height 2.245 m
    • max. standard boom 14.9 m
    • Carrying capacity 0.58 t
    • at max. reach 14.9 m
    • Weight 1.975 t
    • max. carrying capacity 2.59 t
    • at reach 4.6 m
    • Required power 25-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
