    HMF 1410-K3 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    Load Torque: 123.56kNm – machine length: 2.5m – machine width: 0.825m – machine height: 2.245m – max. standard boom: 10.4m – Carrying capacity: 1.11t

    Technical specs - 1410-K3 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 123.56 kNm
    • machine length 2.5 m
    • machine width 0.825 m
    • machine height 2.245 m
    • max. standard boom 10.4 m
    • Carrying capacity 1.11 t
    • at max. reach 10.4 m
    • Weight 1.79 t
    • max. carrying capacity 2.87 t
    • at reach 4.4 m
    • Required power 25-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
