HMF 1300-K4
- Load Torque:
- 106 kNm
- machine length:
- 2.5 m
- machine width:
- 0.825 m
- machine height:
- 2.25 m
1300-K4 HMF 1300-K4 Specifications & Technical Data (2008—2019)
.jpg)
.jpg)
Technical specs - 1300-K4 HMF
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Load Torque
- 106 kNm
- machine length
- 2.5 m
- machine width
- 0.825 m
- machine height
- 2.25 m
- max. standard boom
- 12.7 m
- at max. reach
- 19.7 m
- Weight
- 1.775 t
- Model series
- K
More technical details, like: carrying capacity, load of additional jib, max. carrying capacity, at reach, max. hook height, required power are available in the full technical specs.
unmounted without accessories LMB = load torque limit Schwb.= pivot range
Special equipment
- Hydr. brace support
-
Yes
- Electronic load torque limitation
-
Yes
- Endless pivoting
-
No
- High seat
-
No
- Remote control
-
No
- Adjustable pivoting
-
Yes
- Articulated boom overstraining
-
No
