    HMF 1220-K5 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    The 1220-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1220-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The 1220-K5 is categorised in the smallest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.5m x 0.747m. 15m is the maximum length of the standard boom for the 1220-K5 crane. The model HMF 1220-K5 offers a maximum load capacity of 2.34t. The load torque of this model is 103kNm.

    It has been sold without Hydr. Brace support, High seat and Articulated boom overstraining as of 2018. Get the original HMF 1220-K5 datasheet for even more detailed specifications and machine details. Available in German, French, English and Spanish, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    Manufacturing of this model is still ongoing.

    HMF currently produces 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm - the most visited on LECTURA Specs are 260-T2, 6020-K6 , 340-K2 . Having been in production from 2016 to 2018, the 1220-K5 hydraulic loading crane ranks in the LECTURA index at #3112. Want more detailed specifications? Download the latest HMF 1220-K5 specs data sheet on LECTURA Specs today!

    Technical specs - 1220-K5 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 103 kNm
    • machine length 2.5 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 15 m
    • Carrying capacity 0.54 t
    • at max. reach 14.9 m
    • Weight 1.53 t
    • max. carrying capacity 2.34 t
    • at reach 4.5 m
    • Required power 22 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
