    HMF 1220-K2 Specifications & Technical Data (2016-2021)

    Rate this machine now!

    The 1220-K2 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1220-K2 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The HMF 1220-K2 can be grouped in the smallest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.5m x 0.747m. 8.2m is the maximum length of the standard boom for the 1220-K2 crane. 2.69t is the maximum carrying capacity of this HMF 1220-K2 crane, according to its specification. The stated load torque of the HMF 1220-K2 is 112kNm.

    Electronic load torque limitation, Articulated boom overstraining and Adjustable pivoting are not provided on this model as of 2018. More detailed specifications and machine descriptions can be found in the original HMF 1220-K2 specs data sheet. Available in German, English, Spanish and French, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    Manufacturing of this model is still ongoing.

    At present, 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm are produced by HMF. Of these, 260-T2, 340-K2 and also 6020-K6 are the most frequently visited on LECTURA Specs. Ranked in the LECTURA index at #3051, this 1220-K2 hydraulic loading crane has models that date from 2016 to 2018. Want more detailed specifications? Download the latest HMF 1220-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 1220-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 112 kNm
    • machine length 2.5 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 8.2 m
    • Carrying capacity 1.36 t
    • at max. reach 8.2 m
    • Weight 1.24 t
    • max. carrying capacity 2.69 t
    • at reach 4.2 m
    • Required power 22-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
