    HMF 1030-K5 Specifications & Technical Data (2017-2021)

    Rate this machine now!

    The 1030-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1030-K5 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The 1030-K5 is categorised in the smallest machine segment in the hydraulic loading crane category. Dimensions of 1030-K5 model are 2.35m length and 0.747m width. The max. Standard boom of this HMF model is 14m. The 1030-K5 Hydraulic Loading Crane has a maximum capacity of 2.19t. The manufacturer's datasheet guarantees 88kNm in load torque.

    Electronic load torque limitation, Hydr. Brace support and Endless pivoting are not provided on this model as of 2018. Find detailed specifications and machine details in the original HMF 1030-K5 datasheet. Available in English, French, German and Spanish, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    To this day, this machine is still being manufactured.

    HMF currently produces 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm - the most visited on LECTURA Specs are 6020-K6 , 340-K2 , 260-T2. Having been in production from 2017 to 2018, the 1030-K5 hydraulic loading crane ranks in the LECTURA index at #3563. Want more detailed specifications? Download the latest HMF 1030-K5 specs data sheet on LECTURA Specs today!

    Technical specs - 1030-K5 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 88 kNm
    • machine length 2.35 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 14 m
    • Carrying capacity 0.5 t
    • at max. reach 14 m
    • Weight 1.36 t
    • max. carrying capacity 2.19 t
    • at reach 4.1 m
    • Required power 22 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
