    HMF 1020-K4 Specifications & Technical Data (2017-2021)

    Rate this machine now!

    The 1020-K4 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1020-K4 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The 1020-K4 is categorised in the smallest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.35m x 0.747m. 11.8m is the maximum length of the standard boom for the 1020-K4 crane. The 1020-K4 Hydraulic Loading Crane has a maximum capacity of 2.21t. This model is constructed to deliever a load torque of 87kNm.

    It does not include Remote control, Adjustable pivoting and High seat. Get the original HMF 1020-K4 datasheet for even more detailed specifications and machine details. You can download it for free in Spanish, German, English and French on LECTURA Specs.

    The production of the 1020-K4 is still going on.

    The most commonly viewed HMF models of this type on LECTURA Specs are the 340-K2 , 6020-K6 and 260-T2, and 429 other hydraulic loading cranes are currently available, ranging from 5kNm up to 756kNm. This 1020-K4 hydraulic loading crane, which was produced between 2017 and 2018 ranks in the LECTURA index at #3323. Want more detailed specifications? Download the latest HMF 1020-K4 specs data sheet on LECTURA Specs today!

    Technical specs - 1020-K4 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 87 kNm
    • machine length 2.35 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 11.8 m
    • Carrying capacity 0.65 t
    • at max. reach 11.8 m
    • Weight 1.305 t
    • max. carrying capacity 2.21 t
    • at reach 4 m
    • Required power 22 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
