    HMF 1010-K2 Specifications & Technical Data (2017-2021)

    Rate this machine now!

    Manufactured by HMF, this is the 1010-K2 hydraulic loading crane. Find and download detailed specs and data sheets for this machin... Read more

    Manufactured by HMF, this is the 1010-K2 hydraulic loading crane. Find and download detailed specs and data sheets for this machine here.

    The 1010-K2 is categorised in the smallest machine segment in the hydraulic loading crane category. This model is 2.35m long and 0.747m wide. The main boom in its maximum length measures 7.5m. The HMF 1010-K2 can carry up to 2.52t. HMF 1010-K2 has 95kNm in load torque.

    It has been sold without High seat, Remote control and Adjustable pivoting as of 2018. Find detailed specifications and machine details in the original HMF 1010-K2 datasheet. Specification sheet is available for a free download in Spanish, English, French and German - providing the machine descriptions and more detailed specs about this particular model.

    The production of the 1010-K2 is still going on.

    The most commonly viewed HMF models of this type on LECTURA Specs are the 340-K2 , 260-T2 and 6020-K6 , and 429 other hydraulic loading cranes are currently available, ranging from 5kNm up to 756kNm. Ranked in the LECTURA index at #3266, this 1010-K2 hydraulic loading crane has models that date from 2017 to 2018. Want more detailed specifications? Download the latest HMF 1010-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 1010-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 95 kNm
    • machine length 2.35 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 7.5 m
    • Carrying capacity 1.27 t
    • at max. reach 7.5 m
    • Weight 1.09 t
    • max. carrying capacity 2.52 t
    • at reach 3.8 m
    • Required power 22-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
