    HMF 1010-K1 Specifications & Technical Data (2017-2021)

    Rate this machine now!

    Manufactured by HMF, this is the 1010-K1 hydraulic loading crane. Find and download detailed specs and data sheets for this machin... Read more

    Manufactured by HMF, this is the 1010-K1 hydraulic loading crane. Find and download detailed specs and data sheets for this machine here.

    This HMF Hydraulic Loading Crane belongs to the smallest machine segment in the hydraulic loading crane category. Dimensions of 1010-K1 model are 2.35m length and 0.747m width. The max. Standard boom of this HMF model is 5.5m. The HMF 1010-K1 can carry up to 2.65t. This model is constructed to deliever a load torque of 98kNm.

    It does not include Hydr. Brace support, Articulated boom overstraining and Adjustable pivoting. Find detailed specifications and machine details in the original HMF 1010-K1 datasheet. Specification sheet is available for a free download in French, Spanish, German and English - providing the machine descriptions and more detailed specs about this particular model.

    The production of the 1010-K1 is still going on.

    The most commonly viewed HMF models of this type on LECTURA Specs are the 340-K2 , 260-T2 and 6020-K6 , and 429 other hydraulic loading cranes are currently available, ranging from 5kNm up to 756kNm. This 1010-K1 hydraulic loading crane, which was produced between 2017 and 2018 ranks in the LECTURA index at #3481. Want more detailed specifications? Download the latest HMF 1010-K1 specs data sheet on LECTURA Specs today!

    Technical specs - 1010-K1 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 98 kNm
    • machine length 2.35 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 5.5 m
    • Carrying capacity 1.84 t
    • at max. reach 5.5 m
    • Weight 0.985 t
    • max. carrying capacity 2.65 t
    • at reach 3.8 m
    • Required power 22-38 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
