Fassi F 1950 RA 2.28 he-dynamic Specifications & Technical Data (2012-2025)

The Fassi F 1950 RA 2.28 he-dynamic is a truck-mounted loading crane manufactured by Fassi since 2012. It has a weight of 14.25 to…

The Fassi F 1950 RA 2.28 he-dynamic is a truck-mounted loading crane manufactured by Fassi since 2012. It has a weight of 14.25 tons and a carrying capacity of 2.25 tons. The load torque is 1950 kNm, and it has a maximum carrying capacity of 30 tons. At its maximum reach of 26.8 meters, it can lift heavy loads. The crane has a maximum standard boom length of 19.4 meters. The machine itself has a length of 2.545 meters, a width of 2.875 meters, and a height of 2.645 meters. At a reach of 4.3 meters, it can still perform its functions. It is equipped with special features such as an articulated boom overstraining, electronic load torque limitation, endless pivoting, hydraulic brace support, and a remote control.

Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic
Hydraulic loading cranes Fassi F 1950 RA 2.28 he-dynamic

Technical specs - F 1950 RA 2.28 he-dynamic Fassi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
1950 kNm
machine length
2.545 m
machine width
2.875 m
machine height
2.645 m
max. standard boom
19.4 m
Carrying capacity
2.25 t
at max. reach
26.8 m
Weight
14.25 t
max. carrying capacity
30 t
at reach
4.3 m
Model series
RA

More technical details, like: load of additional jib, max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
Yes
Electronic load torque limitation
Yes
Endless pivoting
Yes
High seat
No
Remote control
Yes
Adjustable pivoting
No
Articulated boom overstraining
Yes
