Effer 505 6S Specifications & Technical Data (2017-2023)

Rate this machine now!

The 505 6S hydraulic loading crane model is manufactured by Effer. Find and download detailed specs and data sheets for this machi... Read more

The 505 6S hydraulic loading crane model is manufactured by Effer. Find and download detailed specs and data sheets for this machine here.

The 505 6S is categorised in the biggest machine segment in the hydraulic loading crane category. Dimensions of 505 6S model are 7.83m length and 1.475m width. The longest standard boom the Effer 505 6S can have is 16.86m. The 505 6S Hydraulic Loading Crane has a maximum capacity of 13.6t. The stated load torque of the Effer 505 6S is 418kNm.

Remote control, Electronic load torque limitation and Hydr. Brace support are not provided on this model as of 2018. Get the original Effer 505 6S datasheet for even more detailed specifications and machine details. You can download it for free in Spanish, English, French, German and Italian on LECTURA Specs.

To this day, this machine is still being manufactured.

Want more detailed specifications? Download the latest Effer 505 6S specs data sheet on LECTURA Specs today!

Technical specs - 505 6S Effer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Load Torque 418 kNm
  • machine length 7.83 m
  • machine width 1.305 m
  • machine height 2.45 m
  • max. standard boom 16.86 m
  • Carrying capacity 2.12 t
  • at max. reach 16.86 m
  • Load of additional Jib 0.47 t
  • Weight 5.47 t
  • max. carrying capacity 13.6 t
  • at reach 3.01 m
  • Model series Jib 6S Heavy duty

More technical details, like: max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

  • Hydr. brace support
  • Electronic load torque limitation
  • Endless pivoting
  • High seat
  • Remote control
  • Adjustable pivoting
  • Articulated boom overstraining
