1855 L9S Effer 1855 L9S Specifications & Technical Data (2017—2026)

The Effer 1855 L9S is a hydraulic loading crane manufactured by Effer since 2017. It has a weight of 15.295 tons and a carrying ca…

The Effer 1855 L9S is a hydraulic loading crane manufactured by Effer since 2017. It has a weight of 15.295 tons and a carrying capacity of 2.93 tons. The load torque is 1130 kNm and the maximum carrying capacity is 20.73 tons. At its maximum reach of 26.48 meters, it can carry a load of 0.285 tons with the additional jib. The crane has a maximum standard boom length of 26.48 meters and at its maximum reach of 43.05 meters, it can reach a distance of 5.56 meters.

Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S
Hydraulic loading cranes Effer 1855 L9S

Technical specs - 1855 L9S Effer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
1130 kNm
max. standard boom
26.48 m
Carrying capacity
2.93 t
at max. reach
26.48 m
Load of additional Jib
0.285 t
Weight
15.295 t
max. carrying capacity
20.73 t
at reach
5.56 m
Model series
Big

More technical details, like: machine length, machine width, machine height, max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
No
Articulated boom overstraining
No
