    Technical specs - 25500 E6 A.S.C. Cormach

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    machine length 1.07 m
    machine width 2.5 m
    machine height 2.23 m
    max. standard boom 15.5 m
    Carrying capacity 0.94 t
    at max. reach 15 m
    Load of additional Jib 0.66 t
    at max. reach 20 m
    Weight 3.29 t
    max. carrying capacity 8.5 t
    at reach 2 m
    Load Torque ###
    max. hook height ###
    Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    25500 E6 A.S.C. Cormach - Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
