K 430.26 6X4 R MEDIUM E6 Renault (2013 - 2022) lorry truck specs & dimensions

Cab

Cab exterior: Night & Day cab. All steel Cab, electro-zinc plated and cataphoric paint treatment. Cab paint colour: White ekla, technical code: 09350. Red badge. Black front face finish. Four point mechanical cab suspension. Two side doors of which one is accessible from inside the cab. 2 heated, remote control rear view mirrors. 2 wide angle rearview mirrors. Kerb view mirror. Rear view mirrors for bodywork up to 2.55 m wide. Fold-back front view mirror. Air horn. Front wing mudflaps. Basic accessories: cab colour. External sun visor. Tinted, laminated windscreen. Without rear window. Cab interior: Performance finish. Quality roof console, 1 storage compartment with key lock, 1 storage space with net and 4 ISO modules. Interior sun blind on windscreen. DTCO 4.0 digital chronotachograph. Manually operated roof hatch. Mosquito net on air vent. Air-suspended driver's seat with fitted seat belt. Driver's armrest. Safety belt warning.

Options

Cast iron engine flywheel casing. Automatic engine cut-off (5 min). Engine rear power take-off: Flange output DIN 100.

Retarder

OPTIBRAKE (power rating 300 kW at 2300 rpm): combination of the exhaust brake and valve compression braking, coupled to service brake.

Steering

Power steering, variable-flow hydraulic pump. Steering ratio 20:1 - Steering wheel diameter 460 mm. Driving on the right.

Packs

Pack "Fuel Eco" comprising: Gearshifting strategy optimised for FUEL ECO ECO Cruise control with Optiroll Disengageable air compressor Hydraulic power steering, variable flow pump Automatic engine cut-off (5 min) Power mode inhibited after passing the 'hard spot' of the accelerator pedal. Pack "Fuel Eco" comprising: ECO Cruise control with Optiroll Disengageable air compressor Hydraulic power steering, variable flow pump Automatic engine cut-off (5 min) Power mode inhibited after passing the 'hard spot' of the accelerator pedal Optivision Map Based gear shift strategy for FUEL ECO (anticipation of topography and centralised data storage). Telematics pre-equipment including TGW (Telematics Gateway) - version 3G for Optivision. Pack "Protect" comprising: Stop lights emergency lighting Additional cornering lights Front fog lights Automatic windscreen wiping with rain sensor Automatic lights ISO_11992 compatible tyre pressure monitoring system.

Gearbox

Optidriver AT 2612F gearbox (14.94 - 1) with automatic clutch. Aluminium housing. Max. torque 2550 Nm, 12 forwards gears and 3 reverse gears. Steering wheel-mounted operating mode selection (automatic/manual) via gear shift selector. Gearbox rear intermediate housing in aluminium. Gearbox oil cooler, oil/water heat exchanger.

Steering Wheel Equipment

"Performance" 4-spoke steering wheel adjustable for height and depth, with control for cruise control. OPTIDRIVER control. OPTIBRAKE and retarder control on right-hand side. Easy Access steering column adjustable in 2 directions. Removable writing board on steering wheel.
