X6 4243 S Ginaf (2017 - 2026) lorry truck specs & dimensions

The Ginaf X6 4243 S is a rigid chassis truck manufactured by Ginaf since 2017. It is equipped with an engine power of 270 kW and has a gross vehicle weight of 43 tons.

Trucks Rigid Chassis Ginaf X6 4243 S
Trucks Rigid Chassis Ginaf X6 4243 S
Trucks Rigid Chassis Ginaf X6 4243 S
Trucks Rigid Chassis Ginaf X6 4243 S

Technical specs - X6 4243 S Ginaf

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Gross vehicle weight
43 t
Drive type
8x4
Engine power
270-390 kW
Emission standard
EURO VI
Front suspension
B
Rear suspension
B
Transmission type
A/man.
Model series
X6

More technical details, like: gross combination weight, wheelbase, cab are available in the full technical specs.

Download datasheets (PDF)

Ginaf X6 4243 S overview

Safety

Safety

Euro 6 engines HPVS: level transverse control HPVS: integrated roll stabilisation HPVS: Container pull-up system HPVS: silo system Brakes (up to 3-fold/separated braking system)


Dimensions / Weight / Chassis

Type designation GINAF trucks

The meaning of the four digits is explained with the following example: GINAF X6 4444 TS-H. X6 stands for DAF CF cab of the EURO 6 type. The first digit indicates the total number of axles: 4 The second 4 indicates the number of driven axles: 4. (A HydroAxle+ also counts as a max. 9-tonne driven axle here.) The number 44 stands for the maximum legal vehicle weight: 44 tonnes (rounded up from 43.5 tonnes) TS-H indicates that the vehicle is fitted with a TRIDEM® arrangement, an EVS steered rigid rear axle and a HydroAxle+.


Payload

High legal axle loads HPVS: even axle load distribution TRIDEM® axle arrangement (possible with 4-axles and 5-axles) Low unladen weight.
