Technical specs - APH 1000 TC Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 750 kg
- Centrifugal force
- 70 kN
- Working width
- 800 mm
- Vibrating frequency
- 46 Hz
- Power source
- D
- Model series
- APH
- Engine manuf.
- Hatz
- Engine type
- 1D90V
- Engine power
- 10.9 kW
- Revolutions at max torque
- 3000 rpm
More technical details, like: dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Download datasheets (PDF)
Events
Visit Ammann live at
Buy & Rent
Compare Ammann APH 1000 TC with similar Reversible Vibratory Plate Compactors
.jpg)
Ammann APH 1000 TC
- Weight:
- 750 kg
- Centrifugal force:
- 70 kN
- Working width:
- 800 mm
- Vibrating frequency:
- 46 Hz
Vibromax ATS 6002
- Weight:
- 798 kg
- Centrifugal force:
- 60 kN
- Working width:
- 680 mm
- Vibrating frequency:
- 30.5 Hz
PowerPac PPR 6000
- Weight:
- 850 kg
- Centrifugal force:
- 60 kN
- Working width:
- 650 mm
- Vibrating frequency:
- 33 Hz
