Rammax DS 68
- Weight:
- 83 kg
- Tamper amplitude:
- 60 mm
- Tamper width:
- 280 mm
- max. No. of strokes:
- 730 1/min
Rammax DS 68 Specifications & Technical Data (1996-2002)
Technical specs - DS 68 Rammax
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 83 kg
- Tamper amplitude
- 60 mm
- Tamper width
- 280 mm
- max. No. of strokes
- 730 1/min
- Power source
- Diesel
- Engine manuf.
- Yanmar
- Engine type
- L40
- Engine power
- 3 kW
More technical details, like: single stroke energy, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Special equipment
- Tamper width variable
-
No
- driving device
-
No
