Endress ESE 220 DW-B Specifications & Technical Data (2011-2016)

Rate this machine now!

Nominal output: 220KVA – Nominal current: 296A – Nominal voltage: 400V – Weight: 2784kg – Type of cooling: w – Transport length: 3.5m

Technical specs - ESE 220 DW-B Endress


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal output 220 KVA
  • Nominal current 296 A
  • Nominal voltage 400 V
  • Weight 2784 kg
  • Type of cooling w
  • Transport length 3.5 m
  • Transport width 1.208 m
  • Transport height 1.95 m
  • Model series ESE 220
  • Engine manuf. Deutz
  • Engine type BF6M2013FC-G2
  • Engine power 175 kW

More technical details, like: average fuel consumption, fuel consumption range (min - max), carriage, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model

Special equipment

  • Electric starter
  • silenced
  • Earth leakage monitor
  • Automatic oil deficiency shutoff
  • Thermo magnetic switch
  • Ground fault circuit interrupter
