    Technical specs - MSC 8500M-2D Rubble Master

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 32 t
    Transport length 17.7 m
    Transport width 3 m
    Transport height 3.4 m
    Type of screen MS
    Plant type RM
    Screen width 1.525 m
    Screen length 5.485 m
    Hopper capacity 9.2 m³
    Main conveyor width 1050 mm
    Side conveyor width 800 mm
    Drive ###
    Drive power ###
    Maximum Number of screens ###

    Type of plant: KU = skid unit, PB = impeller breaker , RM = mobile track, RA = mobile wheeled, CO = with container
