Vector 4S Eliet Vector 4S Specifications & Technical Data (2023—2026)

Weight (w/o. accessory): 257kg – Engine type: B – Engine power: 9.6kW – Output: 3m³/h – Drive: M – Outlet: 80mm

Waste Disposal Wood Chippers Eliet Vector 4S

Technical specs - Vector 4S Eliet

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight (w/o. accessory)
257 kg
Engine type
B
Engine power
9.6 kW
Output
3 m³/h
Drive
M
Outlet
80 mm
Attachment
FG
Intake
W
Model series
Vector
Engine manuf.
Honda
Dimension lxwxh
407x485x449 mm
Displacement
0.389 l
Revolutions at max torque
2500 rpm
Max. torque
26.4 Nm
No. of cylinders
1
Cylinder bore x stroke
88x64 mm
Weight
31.5 kg
Emission level
V

More technical details, like: engine manufactor, travel speed are available in the full technical specs.

Basic model with blade and mounting resp. trailing device with power take-off: G incl. articulated shaft, M incl. motor, H incl. hydraulic motor and hoses

Special equipment

conveyor belt
No
Self-propelled
No
Crawler
No
Fast running axle up to 80 km/h
No
