    John Deere 1010 E Specifications & Technical Data (2008-2016)

    Rate this machine now!

    Operating weight: 14.7t – Crane manufacturer: John Deere – Type of crane: CF 5 – Standard tyres: 600/650/710 – Boom Lifting Torque: 102kN – Net load: 11t

    Technical specs - 1010 E John Deere


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Operating weight 14.7 t
    • Crane manufacturer John Deere
    • Type of crane CF 5
    • Standard tyres 600/650/710
    • Boom Lifting Torque 102 kN
    • Net load 11 t
    • Transmission type HSM
    • No. of tyres 6
    • Transport length 10.29 m
    • Transport width 2.92 m
    • Transport height 3.6 m
    • Engine manuf. John Deere
    • Engine type 4045HTJ
    • Engine power 116 kW
    • Revolutions at max torque 1400 rpm
    • Max. torque 645 Nm
    • No. of cylinders 4
    • Emission level T3

    More technical details, like: dimension lxwxh, displacement, cylinder bore x stroke, weight are available in the full technical specs.

    Basic model incl. crane and log grab

    Special equipment

    • Track

    Carbon footprint calculation

    Calculate the carbon footprint of the John Deere 1010 E per hour of use:

    Or go directly to ERA Equipment CO2 Calculator

    service provided by ERA
