T4108 Weidemann Telehandler Specs & Dimensions (2014 - 2018)

Name: Weidemann T4108 Telehandlers
Brand: Weidemann

The Weidemann T4108 is a telehandler manufactured from 2014 to 2018. It has a weight of 2 tons and a transport length of 3 meters.…

The Weidemann T4108 is a telehandler manufactured from 2014 to 2018. It has a weight of 2 tons and a transport length of 3 meters. The nominal load at the center of gravity is 0.8 tons, and it has a lifting height of 4.145 meters. The center of gravity is located at 500 millimeters. The travel speed of this telehandler is 14 km/h. It has a transport width of 1.413 meters and a transport height of 1 meter.

T4108

Years of manufacture: 2014—2018

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - T4108 Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 0.8 t

Centre of gravity: 500 mm

Standard tyres: 27x10.0-15 AS ET 20

Transmission type: HY

Lifting height: 4.145 m

Weight: 2.270 t

Transport length: 3.554 m

Transport width: 1.413 m

Transport height: 1.900 m

Travel speed: 14 km/h

Engine manuf.: Yanmar

Engine type: 3TNV76

Engine power: 19.2 kW

Displacement: 1.116 l

Revolutions at max torque: 3000 rpm

No. of cylinders: 3

Emission level: III A

More technical details, like: model series, max. reach horizontal, capacity at full forward reach, capacity at full lift height, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, max. torque, cylinder bore x stroke, cab position, chassis type, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, tyre - front size, tyre 2 - front size option, tyre 3 - front size option, service brake - type, service brake - location, dimension configuration, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - ground with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No

Download datasheets (PDF)
