MLT 960 Manitou Telehandler Specs & Dimensions (2014 - 2020)

The Manitou MLT 960 is a telehandler manufactured by Manitou from 2014 to 2020. It has a weight of 11.4 tons and a transport lengt…

The Manitou MLT 960 is a telehandler manufactured by Manitou from 2014 to 2020. It has a weight of 11.4 tons and a transport length of 6.1 meters. The maximum horizontal reach is 5.3 meters, and it can lift loads up to 6 tons at the nominal center of gravity. The lifting height is 9 meters, and it has a capacity of 1.4 tons at full forward reach. The center of gravity is located at 500 millimeters. At full lift height, it can handle loads up to 3.5 tons. The transport width is 2.48 meters, and the transport height is 2.53 meters.

Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960
Telehandlers Manitou MLT 960

Visit Manitou live at

Technical specs - MLT 960 Manitou

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
6 t
Model series
MLT
Centre of gravity
500 mm
Standard tyres
460/70 R 24
Max. Reach horizontal
5.3 m
Capacity at full forward reach
1.4 t
Lifting height
9 m
Capacity at full lift height
3.5 t
Weight
11.4 t
Transport length
6.1 m
Transport width
2.48 m
Transport height
2.53 m
Engine manuf.
John Deere
Engine type
4045PWX
Engine power
104 kW
Revolutions at max torque
1500 rpm
Max. torque
534 Nm
Emission level
Tier 4 f

More technical details, like: transmission type, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement...

More technical details, like: transmission type, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, attachment quickhitch, telematics available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, breakout force, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, number of boom sections, lift capacity - fork maximum, raise time - boom, extend time - boom, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No
