Samson 75.10 Dieci Telehandler Specs & Dimensions (2015 - 2020)

Name: Dieci Samson 75.10 Telehandlers
Brand: Dieci

The Dieci Samson 75.10 is a telehandler manufactured by Dieci from 2015 to 2020. It has a weight of 12.1 tons and a transport leng…

The Dieci Samson 75.10 is a telehandler manufactured by Dieci from 2015 to 2020. It has a weight of 12.1 tons and a transport length of 5.91 meters. The nominal load at the center of gravity is 7.5 tons, and it has a lifting height of 9 meters. The capacity at full forward reach is 0.3 tons, and the center of gravity is located at 600 millimeters. The travel speed of this telehandler is 40 km/h, and it has a maximum climbing ability of 40 percent. The capacity at full lift height is 4.6 tons. The transport width is 2.38 meters, and the transport height is 2.49 meters. It is equipped with a diesel particulate filter.

Samson 75.10

Years of manufacture: 2015—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Samson 75.10 Dieci

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 7.5 t

Model series: Samson

Centre of gravity: 600 mm

Standard tyres: 18x22.5

Transmission type: HY

Max. Reach horizontal: 5.40 m

Capacity at full forward reach: 0.3 t

Lifting height: 9 m

Capacity at full lift height: 4.6 t

Weight: 12.1 t

Transport length: 5.91 m

Transport width: 2.38 m

Transport height: 2.49 m

Travel speed: 40 km/h

max. climbing ability: 40 %

Engine manuf.: FPT

Engine type: F4HFE413B*A

Engine power: 103 kW

Displacement: 4.485 l

No. of cylinders: 4

Emission level: IIIB/Tier 4i

More technical details, like: drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, emission rating, aspiration, rated speed, engine output - net, engine output - gross, tyre - front size, service brake - type, service brake - location, dimension configuration, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, stabilised lift height - with maximum capacity, turning radius - over tyres, breakout force, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, stabilised lift capacity - maximum, stabilised lift capacity - to max height, stabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: Yes
StVZO Equipment: No
Inclination correction: No
Side displacement: No
