T 204 H Ausa Telehandler Specs & Dimensions (2008 - 2019)

Name: Ausa T 204 H Telehandlers
Brand: Ausa

The Ausa T 204 H is a telehandler manufactured from 2008 to 2019. It has a weight of 4.2 tons and a transport length of 4.664 mete…

The Ausa T 204 H is a telehandler manufactured from 2008 to 2019. It has a weight of 4.2 tons and a transport length of 4.664 meters. The maximum horizontal reach is 2.072 meters, and it can lift a nominal load of 2 tons at the center of gravity. The lifting height is 4.2 meters, and it has a capacity of 1 ton at full forward reach. The center of gravity is located at 500 millimeters. It has a travel speed of 24 km/h and can climb slopes with a maximum gradient of 50 percent. The capacity at full lift height is 2 tons. The transport width is 1.595 meters, and the transport height is 2.03 meters.

T 204 H

Years of manufacture: 2008—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - T 204 H Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 2 t

Model series: T

Centre of gravity: 500 mm

Standard tyres: 10/75-15.3

Transmission type: HY

Max. Reach horizontal: 2.072 m

Capacity at full forward reach: 1 t

Lifting height: 4.2 m

Capacity at full lift height: 2 t

Weight: 4.2 t

Transport length: 4.664 m

Transport width: 1.595 m

Transport height: 2.03 m

Travel speed: 24 km/h

max. climbing ability: 50 %

Engine manuf.: Kubota

Engine type: V2403

Engine power: 36.5 kW

Emission level: III B

More technical details, like: drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, tyre 2 - front size option, tyre 3 - front size option, service brake - type, service brake - location, dimension configuration, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No

Download datasheets (PDF)
