Hubtex MaxX 45 EL electric side loader forklift specs (2021 - 2024)

Rate this machine now!

Nominal load at COG: 4.5t – Construction height: 2610mm – Total width: 2300mm – Standard tyres: 6/2x – Centre of gravity: 600mm – ... Read more

Nominal load at COG: 4.5t – Construction height: 2610mm – Total width: 2300mm – Standard tyres: 6/2x – Centre of gravity: 600mm – Voltage: 48V

MaxX 45 EL electric powered side loader forklift model manufactured by Hubtex in (2021 - 2024). Explore detailed MaxX 45 EL sideway forklift specs: technical details, table charts and data sheets to download. Check also the other side loader models produced by Hubtex.

Technical specs - MaxX 45 EL Hubtex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal load at COG 4.5 t
  • Construction height 2610 mm
  • Total width 2300 mm
  • Standard tyres 6/2x
  • Centre of gravity 600 mm
  • Voltage 48 V
  • Traction motor 8 kW
  • Hoist motor 15 kW
  • Weight 7 t
  • Battery weight 1.28 t
  • Lifting height 4 m
  • Hoisting with / without load 0.23/0.30 m/s
  • Lowering with load 0.35 m/s
  • Model series 2425

More technical details, like: drive system, travel speed with / without load, transmission type are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs without additional hydraulics, battery, charger. With Simplex mast (3,3m up to 10t • 5m > 10t load capacity). L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low-pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel

Special equipment

  • Hydr. brace support
