Technical specs - SRSC45H2 Sany
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 45 t
- Standard tyres
- 18.00-25 40PR
- Weight
- 72 t
- Total width
- 6053 mm
- Construction height
- 4770 mm
- Lifting height
- 15.1 m
- Travel speed with / without load
- 21/25 km/h
- Turning radius
- 8 m
- Wheel base
- 6 m
- Model series
- SRSC
- Engine manuf.
- Cummins
- Engine type
- QSM11-C335
- Engine power
- 250 kW
- Displacement
- 10.8 l
- Revolutions at max torque
- 2100 rpm
- Max. torque
- 1674/1400 Nm
- No. of cylinders
- 6
- Emission level
- III
More technical details, like: centre of gravity, transmission type, max. reach horizontal, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications, prices and weight refer to basic models incl. spreader
