Technical specs - LRS 545 Litronic Liebherr
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 45 t
- Standard tyres
- 18.00 x 25 / 40 PR
- Weight
- 69 t
- Total width
- 4490 mm
- Construction height
- 17800 mm
- Lifting height
- 13.3 m
- Travel speed with / without load
- 25/20 km/h
- Wheel base
- 6.5 m
- Model series
- LRS
- Engine manuf.
- Liebherr
- Engine type
- D 944
- Engine power
- 230 kW
- Displacement
- 7.964 l
- Revolutions at max torque
- 1700 rpm
- Max. torque
- 1440 Nm
- No. of cylinders
- 4
- Emission level
- Tier 4 f
More technical details, like: centre of gravity, transmission type, max. reach horizontal, turning radius, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications, prices and weight refer to basic models incl. spreader
Download datasheets (PDF)
