EJG 216 Jungheinrich Walkie Stacker Specs & Dimensions (2017 - 2023)

Nominal load at COG: 1.6t – Wheel base: 1.37m – Standard tyres: Vu 1x / 2 – Transport length: 2.87m – Transport width: 0.91m – Tra…

Nominal load at COG: 1.6t – Wheel base: 1.37m – Standard tyres: Vu 1x / 2 – Transport length: 2.87m – Transport width: 0.91m – Transport height: 2.165m

EJG 216 walkie stacker manufactured by Jungheinrich in (2017 - 2023). Explore detailed EJG 216 walk behind forklift specs: technical details, table charts and data sheets to download. Check also the other models produced by Jungheinrich.

Pallet Stackers Walkie Stackers Jungheinrich EJG 216

Technical specs - EJG 216 Jungheinrich

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1.6 t
Wheel base
1.37 m
Standard tyres
Vu 1x / 2
Transport length
2.87 m
Transport width
0.91 m
Transport height
2.165 m
Centre of gravity
500 mm
Lifting height
2.8 m
Traction motor
2.8 kW
Hoist motor
3 kW
Battery capacity
24/375 V/Ah
Weight
2.295 t
Battery weight
0.306 t
Travel speed with / without load
6 km/h
Hoisting with / without load
0.15/0.25 m/s
Lowering with load
0.37 m/s
Turning radius
1.87 m
Model series
EJG

Special equipment

Double lift
No
Initial lift
No
Platform foldable
No
Scissor lift
No

Download datasheets (PDF)

Jungheinrich EJG 216 overview

Drive

Intelligent control and drive technology

Jungheinrich 3-phase AC motors with electronic control, tuned perfectly to the application, offering higher performance and low running costs. Make the most of these advantages: High efficiency levels with excellent energy management. Powerful acceleration. Rapid direction change. Maintenance-free drive motor.


Handling

Safe and comfortable stacking and retrieval

All lifting and lowering functions are intuitively controlled with the multifunctional tiller arm. This allows the operator to concentrate fully on stacking and retrieving. Precise, sensitive load lifting by speed controlled and noise-reduced hydraulic motor.


Robust design

The EJG is designed for high-throughput operation: 8-mm steel frame. Closed frame. Robust mast with high residual capacities.


Basic dimensions

Cantilever stacking

The cantilever design, with no interference from support arms, also allows the transport of sideways pallets or special load carriers. The generous ground clearance with 200 mm load wheels also allows the truck to travel over uneven ground and low thresholds. The short overall length makes manoeuvring easier in confined areas.
