Technical specs - 15 ES Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1.5 t
Wheel base
1.383 m
Standard tyres
1x+1/4
Transport length
1.95 m
Transport width
0.82 m
Transport height
1.805 m
Centre of gravity
600 mm
Lifting height
2.5 m
Traction motor
1.5 kW
Hoist motor
3.2 kW
Battery capacity
24/300 V/Ah
Weight
1.23 t
Battery weight
0.3 t
Travel speed with / without load
5.8/6 km/h
Hoisting with / without load
0.12/0.19 m/s
Lowering with load
0.35 m/s
max. climbing ability
15 %
Turning radius
1.575 m

Special equipment

Double lift
No
Initial lift
No
Platform foldable
No
Scissor lift
No

Download datasheets (PDF)

Hyundai 15 ES overview

Drive

Advantages

AC technology gives high performance and low maintenance (no carbon brushes). Intelligent regenerative brake system for fast and efficient handling. Side battery removal, for multiple shift operation. Turtle mode switch, for safe maneuverability with tiller in upright position. Proportional speed control ensures precise operation. Anti roll-back on gradients (parking brake). The motor structure is resistant to dust and moisture. Improved lateral stability thanks to spring-applied castor wheels. Torsion resistant forks, welded type. Increased serviceability by CANbus technology. Grease fittings on all pivot points increase durability. Easy access to all components thanks to removal of only 1-piece front cover.


Structure Design

The closed motor structure is water- and dust resistant (IP 44). Spring-loaded castors improve lateral stability on uneven floors and enhance truck performance and service life. Welded type fork.


Serviceability

CANbus technology reduces wiring complexity. All pivot points have grease fittings and serviceable bushings, to reduce component-wearing. Easy access to all components thanks to removal of 1-piece front cover.


Basic dimensions

Options

Nylon drive wheel and double nylon load wheels Rubber drive wheel and double Polyurethane load wheels Polyurethane drive wheel and single Polyurethane load wheels Nylon drive wheel and single nylon load wheels Fully rubber wrapped handgrip Quick lift (15 strokes to reach max height) Fork length (mm): 800; 900; 1000; 1100; 1220 Overall Fork Width x Length: 685 x 1150 mm Foot pedal release Foot pedal release extra long
