Caterpillar NSS20N2I
- Nominal load at COG:
- 2 t
- Wheel base:
- 1.72 m
- Standard tyres:
- Drive: 250 x 105 / Load: 85 x 70
- Transport length:
- 2.293 m
Caterpillar NSS20N2I Sit Down Rider Pallet Stacker Specs & Dimensions (2024 - 2025)
.jpg)
.jpg)
Technical specs - NSS20N2I Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 2 t
- Wheel base
- 1.72 m
- Standard tyres
- Drive: 250 x 105 / Load: 85 x 70
- Transport length
- 2.293 m
- Transport width
- 1.01 m
- Centre of gravity
- 600 mm
- Traction motor
- 2.7 kW
- Hoist motor
- 4 kW
- Battery capacity
- 24/775 V/Ah
- Weight
- 2.294 t
- Battery weight
- 0.62 t
- Travel speed with / without load
- 9/9 km/h
- Hoisting with / without load
- 0.12/0.22 m/s
- Lowering with load
- 0.33 m/s
- max. climbing ability
- 25.6 %
- Turning radius
- 1.92 m
- Model series
- NSS
More technical details, like: transport height, lifting height are available in the full technical specs.
Special equipment
- Double lift
-
No
- Initial lift
-
Yes
- Scissor lift
-
No
Download specalog and datasheets (PDF)
