Technical specs - OCV 01 Still

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

Nominal load at COG 0.136 t
Wheel base 1.095 m
Transport length 1.44 m
Transport width 0.75 m
Transport height 1.425 m
Aisle Width 1.85 m
Lifting height 3.62 m
Traction motor 0.65 kW
Hoist motor 2.2 kW
Weight 0.75 t
Battery weight 0.05 t
Battery capacity 24/135 V/Ah
Travel speed with / without load 6,0/6,5 km/h
Hoisting with / without load 0,038/0,04 m/s
Lowering with load 0,04/0,038 m/s
Turning radius 1.26 m

More technical details, like: pallet length, pallet width, centre of gravity are available in the full technical specs.

Special equipment

Initial lift
Scissor lift
Lifting platforms
