Lectura specs Forklifts Order Pickers & Cherry Picker Forklifts Order Pickers & Cherry Picker Forklifts Linde Linde V-modular 48V Std. specifications

Linde V-modular 48V Std. order picker specs (2024 - 2024)

Rate this machine now!

Nominal load at COG: 1.2t – Wheel base: 1.628m – Pallet length: 1.2m – Pallet width: 0.8m – Transport length: 3.099m – Transport w... Read more

Nominal load at COG: 1.2t – Wheel base: 1.628m – Pallet length: 1.2m – Pallet width: 0.8m – Transport length: 3.099m – Transport width: 1.08m

V-modular 48V Std. order picker model manufactured by Linde in (2024 - 2024). Explore detailed V-modular 48V Std. cherry picker forklift specs: technical details, table charts and data sheets to download. Check also the other models produced by Linde.

Technical specs - V-modular 48V Std. Linde

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal load at COG 1.2 t
  • Wheel base 1.628 m
  • Pallet length 1.2 m
  • Pallet width 0.8 m
  • Transport length 3.099 m
  • Transport width 1.08 m
  • Transport height 2.29 m
  • Aisle Width 1.38 m
  • Lifting height 8.525 m
  • Centre of gravity 400 mm
  • Traction motor 6.5 kW
  • Hoist motor 13 kW
  • Weight 3.693 t
  • Battery weight 0.933 t
  • Battery capacity 48/620 V/Ah
  • Travel speed with / without load 11 km/h
  • Hoisting with / without load 0,31/0,36 m/s
  • Lowering with load 0.32 m/s
  • Turning radius 2.071 m
  • Model series V

Special equipment

  • Initial lift
  • Scissor lift
  • Lifting platforms
