N25 Linde Order Picker Specs & Dimensions (2021 - 2026)

Nominal load at COG: 2t – Wheel base: 2.22m – Pallet length: 1m – Pallet width: 1.2m – Transport length: 3.76m – Transport width: …

Nominal load at COG: 2t – Wheel base: 2.22m – Pallet length: 1m – Pallet width: 1.2m – Transport length: 3.76m – Transport width: 0.79m

N25 order picker model manufactured by Linde in (2021 - 2026). Explore detailed N25 cherry picker forklift specs: technical details, table charts and data sheets to download. Check also the other models produced by Linde.

Order Pickers & Cherry Picker Forklifts Linde N25
Order Pickers & Cherry Picker Forklifts Linde N25
Order Pickers & Cherry Picker Forklifts Linde N25
Order Pickers & Cherry Picker Forklifts Linde N25
Order Pickers & Cherry Picker Forklifts Linde N25
Order Pickers & Cherry Picker Forklifts Linde N25

Technical specs - N25 Linde

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2 t
Wheel base
2.22 m
Pallet length
1 m
Pallet width
1.2 m
Transport length
3.76 m
Transport width
0.79 m
Transport height
1 m
Aisle Width
4.01 m
Lifting height
0.12 m
Centre of gravity
1200 mm
Traction motor
3 kW
Hoist motor
1.5 kW
Weight
0.97 t
Battery weight
0.29 t
Battery capacity
24/375 V/Ah
Travel speed with / without load
10/12 km/h
Hoisting with / without load
0.06/0.07 m/s
Lowering with load
0.06 m/s
Turning radius
3.2 m
Model series
N

Special equipment

Initial lift
No
Scissor lift
No
Lifting platforms
No

Download datasheets (PDF)

Linde N25 overview

Drive

Safety

The special position of the operator’s platform in front of the battery enables the operator to have the best possible view of the surroundings and to react quickly to dangerous situations. Front LED and optional Linde BlueSpot provide additional safety in the warehouse by visually announcing the vehicle. Three-part brake system adapts flexibly to both the environment and the load weight.


Safety

Service

Up to 1000 operating hours without service check. Maintenance-free three-phase AC technology and adjustment-free brakes reduce service costs. Service components are easily accessible after removal of a service panel. Essential vehicle parameters can be read out via CAN bus connection via laptop. A robust cast-steel bumper on the front protects the operator’s compartment and reduces collision damage.


Equipment

Ergonomics

Operator’s platform with low access for easy boarding and disembarking. Driver’s platform suspension compensates for vibrations and jolts while driving. Height adjustable backrest with foldable seating support offers relief to operators during long transfers. When reversing, a handle behind the backrest provides additional support. Many storage compartments provide space for equipment and personal items.
