S40A Hyster LPG Forklift Specs & Dimensions (2024 - 2026)

Name: Hyster S40A LPG Forklifts
Brand: Hyster

Nominal load at COG: 1.81t – Centre of gravity: 610mm – Standard tyres: 21x7x15 / 16x5x10.5 – Total width: 1070mm – Construction h…

Nominal load at COG: 1.81t – Centre of gravity: 610mm – Standard tyres: 21x7x15 / 16x5x10.5 – Total width: 1070mm – Construction height: 2127mm – Turning radius: 2.005m

Hyster is the manufacturer of the S40A LPG forklift. The production years for this model are (2024 - 2026). Find here detailed specs for S40A LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyster.

S40A

Years of manufacture: 2024—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

See offers

Technical specs - S40A Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 1.81 t

Centre of gravity: 610 mm

Standard tyres: 21x7x15 / 16x5x10.5

Total width: 1070 mm

Construction height: 2127 mm

Turning radius: 2.005 m

max. climbing ability: 36 %

Model series: S

Engine manuf.: Yanmar

Engine type: N/a

Engine power: 42 kW

Displacement: 2.2 l

Revolutions at max torque: 2530 rpm

Max. torque: 174 Nm

No. of cylinders: 4

More technical details, like: transmission type, weight, lifting height, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
