S30FT Hyster LPG Forklift Specs & Dimensions (2019 - 2026)

Nominal load at COG: 1.36t – Centre of gravity: 610mm – Standard tyres: Cushion. 2x/2 – Weight: 2.79t – Total width: 940mm – Const…

Nominal load at COG: 1.36t – Centre of gravity: 610mm – Standard tyres: Cushion. 2x/2 – Weight: 2.79t – Total width: 940mm – Construction height: 2080mm

Hyster is the manufacturer of the S30FT LPG forklift. The production years for this model are (2019 - 2026). Find here detailed specs for S30FT LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyster.

LPG Forklifts Hyster S30FT

Technical specs - S30FT Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1.36 t
Centre of gravity
610 mm
Standard tyres
Cushion. 2x/2
Weight
2.79 t
Total width
940 mm
Construction height
2080 mm
Turning radius
1.96 m
Lifting height
3.23 m
Travel speed with / without load
17.1/17.3 km/h
Hoisting with / without load
0.58/0.60 m/s
Lowering with load
0.51 m/s
max. climbing ability
35 %
Model series
S
Engine manuf.
PSI
Engine type
2.0L
Engine power
33 kW
Displacement
2 l
Revolutions at max torque
1300 rpm
Max. torque
136 Nm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
