H1.8XT - AL Hyster LPG Forklift Specs & Dimensions (2022 - 2026)

Nominal load at COG: 1.75t – Centre of gravity: 500mm – Standard tyres: 21x8-9/18x7-8 – Weight: 2.88t – Total width: 1190mm – Cons…

Nominal load at COG: 1.75t – Centre of gravity: 500mm – Standard tyres: 21x8-9/18x7-8 – Weight: 2.88t – Total width: 1190mm – Construction height: 2160mm

Hyster is the manufacturer of the H1.8XT - AL LPG forklift. The production years for this model are (2022 - 2026). Find here detailed specs for H1.8XT - AL LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyster.

LPG Forklifts Hyster H1.8XT - AL

Technical specs - H1.8XT - AL Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1.75 t
Centre of gravity
500 mm
Standard tyres
21x8-9/18x7-8
Weight
2.88 t
Total width
1190 mm
Construction height
2160 mm
Turning radius
6.025 m
Lifting height
3.035 m
Travel speed with / without load
18/19.5 km/h
Hoisting with / without load
0.615/0.68 m/s
Lowering with load
0.52 m/s
max. climbing ability
33 %
Model series
H
Engine manuf.
GCT
Engine type
K21
Engine power
31 kW
Displacement
2.065 l
Revolutions at max torque
1600 rpm
Max. torque
144 Nm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
