    Lectura specs Forklifts Electric forklifts Electric forklifts Still Still RX 20-14C specifications

    Still RX 20-14C electric forklift specs (2018 - 2022)

    Rate this machine now!

    Nominal load at COG: 1.4t – Standard tyres: SE 2x/2 – Total width: 1099mm – Construction height: 2035mm – Centre of gravity: 500mm... Read more

    Nominal load at COG: 1.4t – Standard tyres: SE 2x/2 – Total width: 1099mm – Construction height: 2035mm – Centre of gravity: 500mm – Drive system: D

    Still is the manufacturer of the RX 20-14C electric forklift. The production years for this model are (2018 - 2022). Find here detailed specs for RX 20-14C electric powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Still.

    Technical specs - RX 20-14C Still

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Nominal load at COG 1.4 t
    • Standard tyres SE 2x/2
    • Total width 1099 mm
    • Construction height 2035 mm
    • Centre of gravity 500 mm
    • Drive system D
    • Voltage 48 V
    • Traction motor 2x6,5 kW
    • Hoist motor 11 kW
    • Weight 2.926 t
    • Battery weight 0.856 t
    • Turning radius 1.487 m
    • Lifting height 3.18 m
    • Travel speed with / without load 16/16 km/h
    • Hoisting with / without load 0,54/0,75 m/s
    • Lowering with load 0,5/0,5 m/s

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs without additional hydraulics, battery, charger. With Simplex mast (3,3m up to 10t • 5m > 10t load capacity). L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low-pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel
