MRT159 Raimondi crane - load chart, specs & dimensions (2017 - 2026)

Name: Raimondi MRT159 Tower Cranes - Trolley Boom - Top-slewing
Brand: Raimondi

Max. load: 10t – max. reach: 65m – Load at max. Reach: 1.65t – Reach at max. Load: 21m – max. standard boom: 65m – min. luffing ji…

Max. load: 10t – max. reach: 65m – Load at max. Reach: 1.65t – Reach at max. Load: 21m – max. standard boom: 65m – min. luffing jib: 26.5m

See load chart, specs, capacity, size and other technical data for Raimondi MRT159 crane manufactured between 2017 - 2026. See information, like: Max. load: 10t – max. reach: 65m – Load at max. Reach: 1.65t – Reach at max. Load: 21m – max. standard boom: 65m – min. luffing jib: 26.5m and more.

Tower Cranes - Trolley Boom - Top-slewing Raimondi MRT159

MRT159

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - MRT159 Raimondi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Max. load: 10 t

max. reach: 65 m

Load at max. Reach: 1.65 t

Reach at max. Load: 21 m

max. standard boom: 65 m

min. luffing jib: 26.5 m

Tower height: 44.25 m

max. hook height: 47.8 m

max. hoisting speed: 136 m/min

Connection load: 95 KVA

Hoist unit: 45 kW

Model series: MRT

More technical details, like: nominal torque, max. luffing jib, ropes, tower system, drive system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: Yes
Add. ballast: Yes
Rail carrier: No
Climbing device: Yes
Undercarriage: Yes
Cross girder: No
