TK 4012 KSD crane - load chart, specs & dimensions (2002 - 2005)

Nominal torque: 645kNm – Max. load: 5t – Load at max. Reach: 1.4t – Reach at max. Load: 12.9m – max. standard boom: 37m – max. hoo…

Nominal torque: 645kNm – Max. load: 5t – Load at max. Reach: 1.4t – Reach at max. Load: 12.9m – max. standard boom: 37m – max. hook height: 28m

See load chart, specs, capacity, size and other technical data for KSD TK 4012 crane manufactured between 2002 - 2005. See information, like: Nominal torque: 645kNm – Max. load: 5t – Load at max. Reach: 1.4t – Reach at max. Load: 12.9m – max. standard boom: 37m – max. hook height: 28m and more.

Tower Cranes - Trolley Boom - Bottom-slewing KSD TK 4012

Technical specs - TK 4012 KSD

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque
645 kNm
Max. load
5 t
Load at max. Reach
1.4 t
Reach at max. Load
12.9 m
max. standard boom
37 m
max. hook height
28 m
Connection load
35 KVA
Hoist unit
19 kW
Model series
TK

More technical details, like: max. reach, max. luffing jib, min. luffing jib, tower height, ropes, max. hoisting speed, tower system, drive system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
Yes
Rail carrier
No
Road Carrige
Yes
Steep jib pos.
Yes
Hot-dipped galvanised
Yes
Ballasting device
Yes
