TK 2610 KSD crane - load chart, specs & dimensions (1999 - 2006)

Nominal torque: 315kNm – Max. load: 3t – Load at max. Reach: 0.85t – Reach at max. Load: 10.5m – max. standard boom: 28m – max. ho…

Nominal torque: 315kNm – Max. load: 3t – Load at max. Reach: 0.85t – Reach at max. Load: 10.5m – max. standard boom: 28m – max. hook height: 19m

See load chart, specs, capacity, size and other technical data for KSD TK 2610 crane manufactured between 1999 - 2006. See information, like: Nominal torque: 315kNm – Max. load: 3t – Load at max. Reach: 0.85t – Reach at max. Load: 10.5m – max. standard boom: 28m – max. hook height: 19m and more.

Tower Cranes - Trolley Boom - Bottom-slewing KSD TK 2610

Technical specs - TK 2610 KSD

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque
315 kNm
Max. load
3 t
Load at max. Reach
0.85 t
Reach at max. Load
10.5 m
max. standard boom
28 m
max. hook height
19 m
Connection load
22 KVA
Hoist unit
13 kW
Model series
TK

More technical details, like: max. reach, max. luffing jib, min. luffing jib, tower height, ropes, max. hoisting speed, tower system, drive system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
No
Rail carrier
No
Road Carrige
No
Steep jib pos.
Yes
Hot-dipped galvanised
Yes
Ballasting device
Yes
