ITK 2610 ITK crane - load chart, specs & dimensions (2009 - 2026)

Max. load: 2.5t – max. reach: 26m – Load at max. Reach: 1t – Reach at max. Load: 12m – max. standard boom: 26m – max. hook height:…

Max. load: 2.5t – max. reach: 26m – Load at max. Reach: 1t – Reach at max. Load: 12m – max. standard boom: 26m – max. hook height: 20m

See load chart, specs, capacity, size and other technical data for ITK ITK 2610 crane manufactured between 2009 - 2026. See information, like: Max. load: 2.5t – max. reach: 26m – Load at max. Reach: 1t – Reach at max. Load: 12m – max. standard boom: 26m – max. hook height: 20m and more.

Tower Cranes - Trolley Boom - Bottom-slewing ITK ITK 2610

Technical specs - ITK 2610 ITK

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Max. load
2.5 t
max. reach
26 m
Load at max. Reach
1 t
Reach at max. Load
12 m
max. standard boom
26 m
max. hook height
20 m
Connection load
21 KVA
Hoist unit
11 kW
Model series
2000

More technical details, like: nominal torque, max. luffing jib, min. luffing jib, tower height, ropes, max. hoisting speed, tower system, drive system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
No
Rail carrier
No
Road Carrige
No
Steep jib pos.
No
Hot-dipped galvanised
No
Ballasting device
No
