Lectura specs Cranes Tower Cranes - Trolley Boom - Bottom-slewing Tower Cranes - Trolley Boom - Bottom-slewing Gru Dalbe Gru Dalbe DB 11 Dalbetta specifications

Gru Dalbe DB 11 Dalbetta crane - load chart, specs (2023 - 2024)

Rate this machine now!

Max. load: 1.2t – max. reach: 18.6m – Load at max. Reach: 0.4t – Reach at max. Load: 9.2m – max. standard boom: 18.6m – max. hoist... Read more

Max. load: 1.2t – max. reach: 18.6m – Load at max. Reach: 0.4t – Reach at max. Load: 9.2m – max. standard boom: 18.6m – max. hoisting speed: 32m/min

See load chart, specs, capacity, size and other technical data for Gru Dalbe DB 11 Dalbetta crane manufactured between 2023 - 2024. See information, like: Max. load: 1.2t – max. reach: 18.6m – Load at max. Reach: 0.4t – Reach at max. Load: 9.2m – max. standard boom: 18.6m – max. hoisting speed: 32m/min and more.

Technical specs - DB 11 Dalbetta Gru Dalbe

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Max. load 1.2 t
  • max. reach 18.6 m
  • Load at max. Reach 0.4 t
  • Reach at max. Load 9.2 m
  • max. standard boom 18.6 m
  • max. hoisting speed 32 m/min
  • Hoist unit 4.5 kW
  • Model series DB

More technical details, like: nominal torque, max. luffing jib, min. luffing jib, tower height, max. hook height, ropes, tower system, drive system, connection load are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

  • Cabin
  • Rail carrier
  • Road Carrige
  • Steep jib pos.
  • Hot-dipped galvanised
  • Ballasting device
