Condecta E 4312 crane - load chart, specs (2011 - 2023)

Name: Condecta E 4312 Tower Cranes - Trolley Boom - Bottom-slewing
Brand: Condecta

Rate this machine now!

Nominal torque: 580kNm – Max. load: 5t – max. reach: 43m – Load at max. Reach: 1.2t – Reach at max. Load: 13.36m – max. standard b... Read more

Nominal torque: 580kNm – Max. load: 5t – max. reach: 43m – Load at max. Reach: 1.2t – Reach at max. Load: 13.36m – max. standard boom: 43m

See load chart, specs, capacity, size and other technical data for Condecta E 4312 crane manufactured between 2011 - 2023. See information, like: Nominal torque: 580kNm – Max. load: 5t – max. reach: 43m – Load at max. Reach: 1.2t – Reach at max. Load: 13.36m – max. standard boom: 43m and more.

Read less

Technical specs
Buy & Rent
Parts & Components
Events & News
Transport
Contacts & Help
Machine inspection

Technical specs - E 4312 Condecta

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

Nominal torque 580 kNm
Max. load 5 t
max. reach 43 m
Load at max. Reach 1.2 t
Reach at max. Load 13.36 m
max. standard boom 43 m
Tower height 36 m
max. hook height 30 m
max. hoisting speed 50 m/min
Drive system FU
Hoist unit 23 kW

More technical details, like: ropes, max. luffing jib, min. luffing jib, tower system, connection load are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
Rail carrier
Road Carrige
Steep jib pos.
Hot-dipped galvanised
Ballasting device
