Lectura specs Cranes Tower Cranes - Trolley Boom - Bottom-slewing Tower Cranes - Trolley Boom - Bottom-slewing Comansa Comansa HT 30 (2,2m) specifications

Comansa HT 30 (2,2m) crane - load chart, specs (1995 - 2008)

Rate this machine now!

Nominal torque: 310kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 9m – max. standard boom: 30m – max. hook hei... Read more

Nominal torque: 310kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 9m – max. standard boom: 30m – max. hook height: 22m

See load chart, specs, capacity, size and other technical data for Comansa HT 30 (2,2m) crane manufactured between 1995 - 2008. See information, like: Nominal torque: 310kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 9m – max. standard boom: 30m – max. hook height: 22m and more.

Technical specs - HT 30 (2,2m) Comansa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Nominal torque 310 kNm
  • Max. load 4 t
  • Load at max. Reach 1 t
  • Reach at max. Load 9 m
  • max. standard boom 30 m
  • max. hook height 22 m
  • Connection load 20 KVA
  • Model series HT

More technical details, like: ropes, max. reach, max. luffing jib, min. luffing jib, tower height, max. hoisting speed, tower system, drive system, hoist unit are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

  • Cabin
  • Rail carrier
  • Road Carrige
  • Steep jib pos.
  • Hot-dipped galvanised
  • Ballasting device
