A 40 Arcomet crane - load chart, specs & dimensions (2011 - 2023)

Name: Arcomet A 40 Tower Cranes - Trolley Boom - Bottom-slewing
Brand: Arcomet

Max. load: 4t – max. reach: 40m – Load at max. Reach: 1t – Reach at max. Load: 12.9m – max. standard boom: 40m – Tower height: 34.…

Max. load: 4t – max. reach: 40m – Load at max. Reach: 1t – Reach at max. Load: 12.9m – max. standard boom: 40m – Tower height: 34.7m

See load chart, specs, capacity, size and other technical data for Arcomet A 40 crane manufactured between 2011 - 2023. See information, like: Max. load: 4t – max. reach: 40m – Load at max. Reach: 1t – Reach at max. Load: 12.9m – max. standard boom: 40m – Tower height: 34.7m and more.

Tower Cranes - Trolley Boom - Bottom-slewing Arcomet A 40

A 40

Years of manufacture: 2011—2023

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - A 40 Arcomet

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Max. load: 4 t

max. reach: 40 m

Load at max. Reach: 1 t

Reach at max. Load: 12.9 m

max. standard boom: 40 m

Tower height: 34.7 m

max. hook height: 41.5 m

max. hoisting speed: 54 m/min

Drive system: E

Connection load: 20 KVA

Hoist unit: 11 kW

Model series: A

More technical details, like: nominal torque, max. luffing jib, min. luffing jib, ropes, tower system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: No
Rail carrier: No
Road Carrige: Yes
Steep jib pos.: Yes
Hot-dipped galvanised: Yes
Ballasting device: No
