Technical specs - SCC20000A Sany
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- max. carrying capacity
- 2000 t
- at reach
- 9 m
- Carrying capacity
- 51 t
- at max. reach
- 116 m
- max. standard boom
- 108 m
- Min. standard boom
- 54 m
- Max. luffing jib
- 216 m
- Engine power
- 746 kW
- Travel speed
- 1.02 km/h
- Model series
- SCC
- Engine manuf.
- Cummins
- Engine type
- QST30
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 4629/1300 Nm
- No. of cylinders
- 12
- Emission level
- Tier II
More technical details, like: max. hook height, load torque, soil pressure, dimension lxwxh, displacement, cylinder bore x stroke, weight are available in the full technical specs.
Including hook block
Special equipment
- 2nd winch
-
No
- Add. ballast
-
No
- Basic boom
-
No
- Tip extension
-
No
